1000VA Automatic Voltage Stabilizer for home
1000VA Automatic Voltage Stabilizer for home
Share |

General (1000VA Automatic Voltage Stabilizer for home)

Neopower 1000VA automatic voltage stabilizer for home is one kind of our competitive products; consist of contact auto voltage regulator, servo motor, automatic control circuit and etc. When the voltage fluctuates or the load varies, automatic sampling control circuit will send signal to drive the servo motor which can adjust the position of carbon brush of auto voltage regulator, then the output voltage will be adjusted to rated value and get a steady state.

This 1000VA automatic voltage stabilizer for home is general type, which has the function of connecting via the commercial power. Compared with other voltage stabilizers, it has the advantage of great variety, complete specification, nice appearance and obvious features of high efficiency, no wave distortion, reliable performance, working continually for long time. Moreover, Neopower automatic voltage stabilizer for home is provided with short time delay and over voltage protection, the long time delay and under voltage protection also can be set according to user requirement. This product is an ideal stabilized voltage supply, widely used in any locations requiring electricity and ensures your power device can run normally.

Performance (Automatic Voltage Stabilizer for home)

Single phase input voltage

160v-250v

Single phase output voltage

0.5KAV-3KAV 220Vand 110v 5KAV-3KAV 220V

Three phase output voltage

Phase voltage 160V-250V Wire voltage 277V-430V

Three-phase output voltage

Phase voltage 220V Wire voltage 380V

Accuracy of voltage stabilization

220V±3% 110V±6%

Frequency

50/60HZ

Adjustable time

<1s (when input voltage has a change of 10%)

Ambient temperature

-5℃--+40℃

Waveform distortion

No additional waveform distortion

Load power factor

0.8

Dielectric strength

1500V/1min

insulation resistance

≥2MΩ
